Image drawing functions, Draw on an image NOTE: Image software-rendering functions (CPU) More...

#include <ImageDrawHelper.hpp>

Collaboration diagram for raylib::image::ImageDrawHelper:

Static Public Member Functions
static void	clearBackground (image::RlImage &dst, const RlColor &color)
	Clear image background with given color. More...

static void	drawPixel (image::RlImage &dst, int posX, int posY, const RlColor &color)
	Draw pixel within an image. More...

static void	drawPixel (image::RlImage &dst, const Vector2f &position, const RlColor &color)
	Draw pixel within an image. More...

static void	drawLine (image::RlImage &dst, int startPosX, int startPosY, int endPosX, int endPosY, const RlColor &color)
	Draw line within an image. More...

static void	drawLine (image::RlImage &dst, const Vector2f &start, const Vector2f &end, const RlColor &color)
	Draw line within an image. More...

static void	drawCircle (image::RlImage &dst, int centerX, int centerY, int radius, const RlColor &color)
	Draw circle within an image. More...

static void	drawCircle (image::RlImage &dst, const Vector2f &center, int radius, const RlColor &color)
	Draw circle within an image. More...

static void	drawRectangle (image::RlImage &dst, int posX, int posY, int width, int height, const RlColor &color)
	Draw rectangle within an image. More...

static void	drawRectangle (image::RlImage &dst, const Vector2f &position, const Vector2f &size, const RlColor &color)
	Draw rectangle within an image. More...

static void	drawRectangleRec (image::RlImage &dst, const Rectangle &rec, const RlColor &color)
	Draw rectangle within an image. More...

static void	drawRectangleLines (image::RlImage &dst, const Rectangle &rec, int thick, const RlColor &color)
	Draw rectangle lines within an image. More...

static void	drawImage (image::RlImage &dst, const image::RlImage &src, const Rectangle &srcRec, const Rectangle &dstRec, const RlColor &tint)
	Draw a source image within a destination image (tint applied to source) More...

static void	drawImageText (image::RlImage &dst, const std::string &text, int posX, int posY, int fontSize, const RlColor &color)
	Draw text (using default font) within an image (destination) More...

static void	drawImageText (image::RlImage &dst, const raylib::text::RlFont &font, const std::string &text, const Vector2f &position, float fontSize, float spacing, const RlColor &tint)
	Draw text (custom sprite font) within an image (destination) More...

Detailed Description

Image drawing functions, Draw on an image NOTE: Image software-rendering functions (CPU)

Member Function Documentation

◆ clearBackground()

void raylib::image::ImageDrawHelper::clearBackground	(	image::RlImage &	dst,
		const RlColor &	color
	)

static

Clear image background with given color.

Parameters

dst	the image to clear
color	the color to use

Here is the call graph for this function:

◆ drawCircle() [1/2]

void raylib::image::ImageDrawHelper::drawCircle	(	image::RlImage &	dst,
		const Vector2f &	center,
		int	radius,
		const RlColor &	color
	)

static

Draw circle within an image.

Parameters

dst	the image to Draw on
center	the position to center at
radius	the radius of the circle
color	the color to use

Here is the call graph for this function:

◆ drawCircle() [2/2]

void raylib::image::ImageDrawHelper::drawCircle	(	image::RlImage &	dst,
		int	centerX,
		int	centerY,
		int	radius,
		const RlColor &	color
	)

static

Draw circle within an image.

Parameters

dst	the image to Draw on
centerX	the x position to center at
centerY	the y position to center at
radius	the radius of the circle
color	the color to use

Here is the call graph for this function:

◆ drawImage()

void raylib::image::ImageDrawHelper::drawImage	(	image::RlImage &	dst,
		const image::RlImage &	src,
		const Rectangle &	srcRec,
		const Rectangle &	dstRec,
		const RlColor &	tint
	)

static

Draw a source image within a destination image (tint applied to source)

Parameters

dst	the image to Draw on
src	the image to Draw
srcRec	the rectangle of the source image to Draw
dstRec	the rectangle of the destination image to Draw on
tint	the color to use

Here is the call graph for this function:

◆ drawImageText() [1/2]

void raylib::image::ImageDrawHelper::drawImageText	(	image::RlImage &	dst,
		const raylib::text::RlFont &	font,
		const std::string &	text,
		const Vector2f &	position,
		float	fontSize,
		float	spacing,
		const RlColor &	tint
	)

static

Draw text (custom sprite font) within an image (destination)

Parameters

dst	the image to Draw on
font	the font to use
text	the text to Draw
position	the position to Draw at
fontSize	the font size to use
spacing	the spacing between letters
tint	the color to use

Here is the call graph for this function:

◆ drawImageText() [2/2]

void raylib::image::ImageDrawHelper::drawImageText	(	image::RlImage &	dst,
		const std::string &	text,
		int	posX,
		int	posY,
		int	fontSize,
		const RlColor &	color
	)

static

Draw text (using default font) within an image (destination)

Parameters

dst	the image to Draw on
text	the text to Draw
posX	the x position to Draw at
posY	the y position to Draw at
fontSize	the font size to use
color	the color to use

Here is the call graph for this function:

◆ drawLine() [1/2]

void raylib::image::ImageDrawHelper::drawLine	(	image::RlImage &	dst,
		const Vector2f &	start,
		const Vector2f &	end,
		const RlColor &	color
	)

static

Draw line within an image.

Parameters

dst	the image to Draw on
start	the position to start at
end	the position to end at
color	the color to use

Here is the call graph for this function:

◆ drawLine() [2/2]

void raylib::image::ImageDrawHelper::drawLine	(	image::RlImage &	dst,
		int	startPosX,
		int	startPosY,
		int	endPosX,
		int	endPosY,
		const RlColor &	color
	)

static

Draw line within an image.

Parameters

dst	the image to Draw on
startPosX	the x position to start at
startPosY	the y position to start at
endPosX	the x position to end at
endPosY	the y position to end at
color	the color to use

Here is the call graph for this function:

◆ drawPixel() [1/2]

void raylib::image::ImageDrawHelper::drawPixel	(	image::RlImage &	dst,
		const Vector2f &	position,
		const RlColor &	color
	)

static

Draw pixel within an image.

Parameters

dst	the image to Draw on
position	the position to Draw at
color	the color to use

Here is the call graph for this function:

◆ drawPixel() [2/2]

void raylib::image::ImageDrawHelper::drawPixel	(	image::RlImage &	dst,
		int	posX,
		int	posY,
		const RlColor &	color
	)

static

Draw pixel within an image.

Parameters

dst	the image to Draw on
posX	the x position to Draw at
posY	the y position to Draw at
color	the color to use

Here is the call graph for this function:

◆ drawRectangle() [1/2]

void raylib::image::ImageDrawHelper::drawRectangle	(	image::RlImage &	dst,
		const Vector2f &	position,
		const Vector2f &	size,
		const RlColor &	color
	)

static

Draw rectangle within an image.

Parameters

dst	the image to Draw on
position	the position to Draw at
size	the size of the rectangle
color	the color to use

Here is the call graph for this function:

◆ drawRectangle() [2/2]

void raylib::image::ImageDrawHelper::drawRectangle	(	image::RlImage &	dst,
		int	posX,
		int	posY,
		int	width,
		int	height,
		const RlColor &	color
	)

static

Draw rectangle within an image.

Parameters

dst	the image to Draw on
posX	the x position to Draw at
posY	the y position to Draw at
width	the width of the rectangle
height	the height of the rectangle
color	the color to use

Here is the call graph for this function:

◆ drawRectangleLines()

void raylib::image::ImageDrawHelper::drawRectangleLines	(	image::RlImage &	dst,
		const Rectangle &	rec,
		int	thick,
		const RlColor &	color
	)

static

Draw rectangle lines within an image.

Parameters

dst	the image to Draw on
rec	the rectangle to Draw
thick	the thickness of the lines
color	the color to use

Here is the call graph for this function:

◆ drawRectangleRec()

void raylib::image::ImageDrawHelper::drawRectangleRec	(	image::RlImage &	dst,
		const Rectangle &	rec,
		const RlColor &	color
	)

static

Draw rectangle within an image.

Parameters

dst	the image to Draw on
rec	the rectangle to Draw
color	the color to use

Here is the call graph for this function:

The documentation for this class was generated from the following files:

raylib-cpp/include/raylib/Image/ImageDrawHelper.hpp
raylib-cpp/src/raylib/Image/ImageDrawHelper.cpp
