raylib::helper::WorldHelper Class Reference

Helper class for world-related functions. More...

#include <WorldHelper.hpp>

Collaboration diagram for raylib::helper::WorldHelper:

Static Public Member Functions
static Vector2f	getWorldToScreen (const Vector3f &position, const RlCamera &camera)
	Get the screen space position for a 3d world space position. More...
static Vector2f	getWorldToScreenEx (const Vector3f &position, const RlCamera &camera, int width, int height)
	Get size position for a 3d world space position. More...
static Vector2f	getWorldToScreen2D (const Vector2f &position, const Camera2D &camera)
	Get the screen space position for a 2d camera world space position. More...
static Vector2f	getScreenToWorld2D (const Vector2f &position, const Camera2D &camera)
	Get the world space position for a 2d camera screen space position. More...

Detailed Description

Helper class for world-related functions.

Member Function Documentation

getScreenToWorld2D()

Vector2f raylib::helper::WorldHelper::getScreenToWorld2D ( const Vector2f &  position, const Camera2D &  camera  )

static

Get the world space position for a 2d camera screen space position.

Parameters

position	the 2d camera screen space position
camera	the camera

Returns

the world space position

Here is the call graph for this function:

getWorldToScreen()

Vector2f raylib::helper::WorldHelper::getWorldToScreen ( const Vector3f &  position, const RlCamera &  camera  )

static

Get the screen space position for a 3d world space position.

Parameters

position	the 3d world space position
camera	the camera

Returns

the screen space position

Here is the call graph for this function:

getWorldToScreen2D()

Vector2f raylib::helper::WorldHelper::getWorldToScreen2D ( const Vector2f &  position, const Camera2D &  camera  )

static

Get the screen space position for a 2d camera world space position.

Parameters

position	the 2d camera world space position
camera	the camera

Returns

the screen space position

Here is the call graph for this function:

getWorldToScreenEx()

Vector2f raylib::helper::WorldHelper::getWorldToScreenEx ( const Vector3f &  position, const RlCamera &  camera, int  width, int  height  )

static

Get size position for a 3d world space position.

Parameters

position	the 3d world space position
camera	the camera
width	the screen width
height	the screen height

Returns

the screen space position

Here is the call graph for this function:

---

The documentation for this class was generated from the following files:

• raylib-cpp/include/raylib/Core/WorldHelper.hpp
• raylib-cpp/src/raylib/Core/WorldHelper.cpp
