Helper class for drawing textures. More...

#include <DrawTextureHelper.hpp>

Collaboration diagram for raylib::helper::draw::DrawTextureHelper:

Static Public Member Functions
static void	drawTexture (const texture::RlTexture &texture, int posX, int posY, const RlColor &tint)
	Draw a texture. More...

static void	drawTexture (const texture::RlTexture &texture, const Vector2f &position, const RlColor &tint)
	Draw a texture with position defined as Vector2f. More...

static void	drawTexture (const texture::RlTexture &texture, const Vector2f &position, float rotation, float scale, const RlColor &tint)
	Draw a texture with extended parameters. More...

static void	drawTextureRec (const texture::RlTexture &texture, const Rectangle &source, const Vector2f &position, const RlColor &tint)
	Draw a part of a texture defined by a rectangle. More...

static void	drawTextureQuad (const texture::RlTexture &texture, const Vector2f &tiling, const Vector2f &offset, const Rectangle &quad, const RlColor &tint)
	Draw a texture quad with tiling and offset parameters. More...

static void	drawTextureTiled (const texture::RlTexture &texture, const Rectangle &source, const Rectangle &dest, const Vector2f &origin, float rotation, float scale, const RlColor &tint)
	Draw part of a texture (defined by a rectangle) with rotation and scale tiled into dest. More...

static void	drawTexture (const texture::RlTexture &texture, const Rectangle &source, const Rectangle &dest, const Vector2f &origin, float rotation, const RlColor &tint)
	Draw a part of a texture defined by a rectangle with 'pro' parameters. More...

static void	drawTextureNPatch (const texture::RlTexture &texture, const NPatchInfo &nPatchInfo, const Rectangle &dest, const Vector2f &origin, float rotation, const RlColor &tint)
	Draws a texture (or part of it) that stretches or shrinks nicely. More...

static void	drawTexturePoly (const texture::RlTexture &texture, const Vector2f &center, const std::vector< Vector2f > &points, std::vector< Vector2f > &texcoords, const RlColor &tint)
	Draw a textured polygon. More...

Detailed Description

Helper class for drawing textures.

Member Function Documentation

◆ drawTexture() [1/4]

void raylib::helper::draw::DrawTextureHelper::drawTexture	(	const texture::RlTexture &	texture,
		const Rectangle &	source,
		const Rectangle &	dest,
		const Vector2f &	origin,
		float	rotation,
		const RlColor &	tint
	)

static

Draw a part of a texture defined by a rectangle with 'pro' parameters.

Parameters

texture	the texture to Draw
source	the rectangle of the texture to Draw
dest	the rectangle of the texture to Draw into
origin	the origin of the texture
rotation	the rotation of the texture
tint	the color tint of the texture

Here is the call graph for this function:

◆ drawTexture() [2/4]

void raylib::helper::draw::DrawTextureHelper::drawTexture	(	const texture::RlTexture &	texture,
		const Vector2f &	position,
		const RlColor &	tint
	)

static

Draw a texture with position defined as Vector2f.

Parameters

texture	the texture to Draw
position	the position of the texture
tint	the color tint of the texture

Here is the call graph for this function:

◆ drawTexture() [3/4]

void raylib::helper::draw::DrawTextureHelper::drawTexture	(	const texture::RlTexture &	texture,
		const Vector2f &	position,
		float	rotation,
		float	scale,
		const RlColor &	tint
	)

static

Draw a texture with extended parameters.

Parameters

texture	the texture to Draw
position	the position of the texture
rotation	the rotation of the texture
scale	the scale of the texture
tint	the color tint of the texture

Here is the call graph for this function:

◆ drawTexture() [4/4]

void raylib::helper::draw::DrawTextureHelper::drawTexture	(	const texture::RlTexture &	texture,
		int	posX,
		int	posY,
		const RlColor &	tint
	)

static

Draw a texture.

Parameters

texture	the texture to Draw
posX	the x position of the texture
posY	the y position of the texture
tint	the color tint of the texture

Here is the call graph for this function:

Here is the caller graph for this function:

◆ drawTextureNPatch()

void raylib::helper::draw::DrawTextureHelper::drawTextureNPatch	(	const texture::RlTexture &	texture,
		const NPatchInfo &	nPatchInfo,
		const Rectangle &	dest,
		const Vector2f &	origin,
		float	rotation,
		const RlColor &	tint
	)

static

Draws a texture (or part of it) that stretches or shrinks nicely.

Parameters

texture	the texture to Draw
nPatchInfo	the rectangle of the texture to Draw
dest	the rectangle of the texture to Draw into
origin	the origin of the texture
rotation	the rotation of the texture
tint	the color tint of the texture

Here is the call graph for this function:

◆ drawTexturePoly()

void raylib::helper::draw::DrawTextureHelper::drawTexturePoly	(	const texture::RlTexture &	texture,
		const Vector2f &	center,
		const std::vector< Vector2f > &	points,
		std::vector< Vector2f > &	texcoords,
		const RlColor &	tint
	)

static

Draw a textured polygon.

Parameters

texture	the texture to Draw
center	the center of the texture
points	the points of the texture
texcoords	the texture coordinates of the texture
tint	the color tint of the texture

Attention: The points and texcoords must have the same size

Exceptions

raylib::ex::InvalidArgumentException if the points and texcoords have different size

Here is the call graph for this function:

◆ drawTextureQuad()

void raylib::helper::draw::DrawTextureHelper::drawTextureQuad	(	const texture::RlTexture &	texture,
		const Vector2f &	tiling,
		const Vector2f &	offset,
		const Rectangle &	quad,
		const RlColor &	tint
	)

static

Draw a texture quad with tiling and offset parameters.

Parameters

texture	the texture to Draw
tiling	the tiling of the texture
offset	the offset of the texture
quad	the quad of the texture
tint	the color tint of the texture

Here is the call graph for this function:

◆ drawTextureRec()

void raylib::helper::draw::DrawTextureHelper::drawTextureRec	(	const texture::RlTexture &	texture,
		const Rectangle &	source,
		const Vector2f &	position,
		const RlColor &	tint
	)

static

Draw a part of a texture defined by a rectangle.

Parameters

texture	the texture to Draw
source	the rectangle of the texture to Draw
position	the position of the texture
tint	the color tint of the texture

Here is the call graph for this function:

Here is the caller graph for this function:

◆ drawTextureTiled()

void raylib::helper::draw::DrawTextureHelper::drawTextureTiled	(	const texture::RlTexture &	texture,
		const Rectangle &	source,
		const Rectangle &	dest,
		const Vector2f &	origin,
		float	rotation,
		float	scale,
		const RlColor &	tint
	)

static

Draw part of a texture (defined by a rectangle) with rotation and scale tiled into dest.

Parameters

texture	the texture to Draw
source	the rectangle of the texture to Draw
dest	the rectangle of the texture to Draw into
origin	the origin of the texture
rotation	the rotation of the texture
scale	the scale of the texture
tint	the color tint of the texture

Here is the call graph for this function:

The documentation for this class was generated from the following files:

raylib-cpp/include/raylib/Draw/DrawTextureHelper.hpp
raylib-cpp/src/raylib/Draw/DrawTextureHelper.cpp
